Living Room + Kitchen 19 m²
Bedroom 8,5 m²
Bathroom / WC 4.5 m²
Hall 4.5 m²
Patio 6 m²
Room 8,5 m²
Width Size 6,48 m
Size measure 8,62 m
GENERAL SYSTEM DESCRIPTION
Special cross-section steel structure profiles produced in roolformer machines made of high standard galvanized sheet.
EXTERIOR WALLS
Outer Coating 8 mm thick cement board.
Inner Coating 8 mm thick cement board.
Thickness 10 cm
Height 250 cm
Insulation 84 mm, 10 kg / M³ B1 fire class polystyrene foam (EPS)
Optional Features
INTERIOR WALLS
Outer Coating 8 mm thick cement board.
Inner Coating 8 mm thick cement board.
Thickness 6 cm
Height 250 cm
Insulation 44 mm, 10 kg / M³ B1 fire rated polystyrene foam (EPS)
Optional Features
ROOF
Roof System It is made with carcass with the help of specially shaped galvanized profiles according to the static calculations made by considering the snow and wind loads according to the climatic regions. It is fixed with screws without the use of welding.
Outer Surface Coating 0,50 mm thick 27 mm * 200 mm deep maroon painted trapezoidal sheet
Insulation The 80 mm thick mattress is made of glass wool.
Optional Features
CEILING
Drywall plates fixed with electrostatic painted aluminum T profiles.
Optional Features
INTERMEDIATE and STAIRS
In two-storey buildings, it consists of specially shaped intermediate floor chassis made of galvanized sheet. In two-storey buildings, the ladder is produced from profiles of 2mm thickness with a frame. Its coating is again made of 2 mm thick sheet metal.
DOORS
Exterior door Steel door (Door frame made of galvanized material)
Internal Door American door (Door frame made of galvanized material)
WINDOWS
Window It is a white colored PVC window with the features specified in the project.
Pine Insulating glass is used.
PAINTS
Exterior Silicone exterior paint. Its color is determined by the BUYER.
Interior Silicone interior paint. Its color is determined by the BUYER.
Ceiling Plastic white ceiling paint
Metal Parts Standard oil painting
ELECTRICAL INSTALLATION
System System Flush installation. The electricity plan is specified in the project.
Materials Lighting fixtures, socket and switches are included.
SANITARY INSTALLATION
System Recessed installation. The plumbing plan is specified in the project.
Materials Toilet bowl, shower tray, pvc pipes, faucets and batteries are included.
RAIN DISCHARGE SYSTEM
It is made by means of PVC rain gutters and descents.
